CrissCross - Immutable Trees, Bidirectional Streams and TCP Tunneling using Private Clusters, Redis Clients and QUIC

CrissCross is an internet switchboard, letting you find data, services and other computers without a centralized service. Users advertise hashes on a cluster's distributed hash table for other users to find. Clusters are private and users cannot join without a secret key. A configurable public layer is provided for bootstrapping.

Status

This is alpha software. Expect bugs and API changes. Please make an issue for any discussion or proposals.

High Level

CrissCross provides tools to manipulate, search and use the following over an encrypted peer-to-peer network:

  • Immutable syncable trees / files / directories / SQL engine
  • Remote Procedure Calls with bi-directional streaming
  • TCP tunneling

CrissCross was designed to build applications. As such it uses the Redis Protocol instead of HTTP, although HTTP gateways are planned. The core is built in Elixir with certain Rust bindings.



Full Features

  • Content-Addressable Immutable Key Value Trees, SQL Engine and File System
  • Use a Redis client to connect from any language
  • Verified remote RPCs with load balancing without centralization
  • Private Clusters - Setup a cluster of nodes to securely share trees and services between them
  • Store polymorphic data like lists, integers, dictionaries and tuples
  • Broadcast data to the network preemptively - Collaborative caching
  • Configurable Maximum TTL for each cluster - Store data for as long as you need
  • Speedy downloads with multiple connections
  • Remotely access trees on other peoples machines to clone or query
  • IPNS-like mutable pointers
  • Encryption per cluster
  • Efficiently iterate over large collections
  • High performance embedded database
  • Automatic network configuration with UPnP
  • Redis pubsub job queues and bidirectional streams

Related Packages

Further Reading

Tour

Binary Executable

While you can compile and run the repository, it is recommended you use the lastest binary releases.

Linux

curl https://github.com/SoCal-Software-Labs/CrissCross/releases/latest/download/crisscross_linux -o ./crisscross_server
chmod +x ./crisscross_server

MacOS 11

curl https://github.com/SoCal-Software-Labs/CrissCross/releases/latest/download/crisscross_macos -o ./crisscross_server
chmod +x ./crisscross_server

And finally execute the command to launch the database and server to connect to the overlay. By default CrissCross will store data in ./data and will look for cluster configurations in ./clusters of the directory you launch the script in.

./crisscross_server

Install the command-line client with pip:

pip install crisscross-py

Manipulating Trees

With CrissCross you insert data into a hash and get a new hash in return. To start a new tree, insert into an empty hash.

Bash

# In bash you get the Base58 Representation
$ crisscross put "" "hello" "world"
2UPodno55iocZqNGGav5MXi6LsFFqqzDvgQm5A9Qr3pebns
$ crisscross get 2UPodno55iocZqNGGav5MXi6LsFFqqzDvgQm5A9Qr3pebns "hello"
world
$ crisscross put 2UPodno55iocZqNGGav5MXi6LsFFqqzDvgQm5A9Qr3pebns "hello2" "world2"
2UPe9oukYYpPvjGthmyazd1CtTQwddc1DNRxWykdxaXuE6M

Programatic Access

You can access the tree programmatically with Python (or any Redis client):

Store arbitrary data... tuples, lists, dictionaries, booleans, integers, floats and atoms. Not just binary text:

>>> client = CrissCross()
>>> location = client.put_multi("", [(("wow", 1.2), {1: (True, None)})])
>>> client.get_multi(location, [("wow", 1.2)])
{1: (True, None)}

Cluster Basics

A cluster consists of 4 immutable pieces of information. There is a PrivateKey which gives the holder permission to ask the cluster to store data. There is the public key that cluster members use to verify the private key. A Cypher is used to encrypt all cluster DHT traffic over the wire. Think of a Cypher as the password to talk to the cluster. Finally there is the Name, which is a Hash of the Cypher and Public keys combined. A user configurable MaxTTL can be set per node and is not cluster wide.

$ crisscross cluster
Name:       2UPkZmzFeeux8C5kVgVXRWMomgZfdHZ4yv2SqndCLrM4PNX
Cypher:     6NDdi5uVtPszZMHTYxt3n7rSiovLuMF1fQJtioz79ND2
PublicKey:  2bDkyNhW9LBRDFpU18XHCY4LiCGTvrBbtyef2YLLQNztv6qW2TQJB98
PrivateKey: wnpv357S2QpEPQTBMehzvf68uTezpnC36XS6XxFxu6nfwFNqaiZFW28x94ELF3JgHxFSyrqx6BUuE3KBpwgoQjEwLkPie5URph
MaxTTL:     86400000

Put this into a yaml file inside a clusters folder

$ crisscross cluster > clusters/my_cluster.yaml

Restart the node so that it picks up the configuration. Now you will be able to announce data to your new cluster. Starting a variable with * causes the system to load a yaml file and replace the value in your command.

# Reference the cluster name
$ crisscross announce *clusters/my_cluster.yaml#Name 2UPe9oukYYpPvjGthmyazd1CtTQwddc1DNRxWykdxaXuE6M
True

You can distribute this YAML file to anybody you wish to join the cluster. Be careful who you give the Private key to as they can push data to the cluster.

Clone and Share Trees

Once you have a hash, you can share it on the network and others can clone it from you. ^defaultcluster is a special string that is replaced with the name of the default bootstrap overlay cluster

# On one machine
$ crisscross announce ^defaultcluster 2UPe9oukYYpPvjGthmyazd1CtTQwddc1DNRxWykdxaXuE6M
True
# On other machine query the tree without fully downloading it
$ crisscross remote_get ^defaultcluster 2UPe9oukYYpPvjGthmyazd1CtTQwddc1DNRxWykdxaXuE6M "hello2"
"world2"
# They can clone the tree to get a local copy
$ crisscross remote_persist ^defaultcluster 2UPe9oukYYpPvjGthmyazd1CtTQwddc1DNRxWykdxaXuE6M
True
$ crisscross get 2UPe9oukYYpPvjGthmyazd1CtTQwddc1DNRxWykdxaXuE6M "hello"
"world"

Premptively Storing Data on a Cluster

If you have the PrivateKey, you can ask the cluster to store your tree. When you push a tree, you use the DHT to find 8 nodes and ask them to store the value. If they agree, they will connect to your node and download the tree and announce it as available for download, keeping it for the specified TTL.

To enable the feature, when distributing your cluster yaml file to peers, include MaxAcceptedSize and list the bytes of the maximum download size you are willing to distribute.

# clusters/my_cluster.yaml
Name:            2UPkZmzFeeux8C5kVgVXRWMomgZfdHZ4yv2SqndCLrM4PNX
Cypher:          6NDdi5uVtPszZMHTYxt3n7rSiovLuMF1fQJtioz79ND2
PublicKey:       2bDkyNhW9LBRDFpU18XHCY4LiCGTvrBbtyef2YLLQNztv6qW2TQJB98
PrivateKey:      wnpv357S2QpEPQTBMehzvf68uTezpnC36XS6XxFxu6nfwFNqaiZFW28x94ELF3JgHxFSyrqx6BUuE3KBpwgoQjEwLkPie5URph
MaxTTL:          86400000
MaxAcceptedSize: 10000000 # ~10mb
# Push a tree onto the cluster
$ crisscross push *clusters/my_cluster.yaml#Name 2UPe9oukYYpPvjGthmyazd1CtTQwddc1DNRxWykdxaXuE6M
True

This enables several interesting usecases:

  • Collaborative Caching - Everybody has the key and accepts other peoples data
  • PubSub like Distribution - One person has the key, with a group of peers following for updates and redistributing
  • Private Hosting - Agree with nodes for them to host your data, encrypt it and send it to them with an infinite TTL

Any data that has a TTL larger than your MaxTTL of the cluster will be rejected so its important for the cluster to agree beforehand.

You can disable this feature by destroying the PrivateKey after generating the cluster configuration or by setting MaxAcceptedSize to 0.

RPC

Generate a new keypair to announce the service under.

crisscross keypair > keys/my_key.yaml

Server

Get a job from the queue. Block until the timeout in ms or a job enters the queue. When you respond, CrissCross will automatically sign the response for you. You can serve multiple responses concurrently off of one connection by using threads or multithreaded queues. You can even serve results out of order. When you respond with the reference, CrissCross will automatically route the reply to the waiting client.

import crisscross as cx

client = cx.CrissCross()
service = cx.read_var("*keys/my_key.yaml#Name")
cluster = cx.read_var("^defaultcluster")
client.job_announce(cluster, service)
while True:
    method, arg, ref = client.job_get(service, timeout=9999999)
    if method == "add_one":
        arg = arg + 1
        client.job_respond(ref, arg, service)

Client

Send a job to the server:

client = cx.CrissCross()
service = cx.read_var("*keys/my_key.yaml#Name")
cluster = cx.read_var("^defaultcluster")
result, signature = client.remote_job_do(cluster, service, "add_one", 42)
print(resp)
print(client.job_verify(service, "method", 42, result, signature, service))

Streams

For a job using bidirectional streams see the example: streams.py

TCP Tunneling

TCP tunnelling allows you to connect to a remote service using another computer. This is useful if you are behind a firewall and need to share a local server or other resource. It also works well if you want to expose a server resource on the CrissCross network.

How to tunnel

Generate a new keypair to announce the tunnel under.

crisscross keypair > ./keys/my_tunnel.yaml

On the server instance, set the environment variable TUNNEL_TOKEN of your CrissCross server (In this example 123) to a secret value and restart your instance. Announce a tunnel under a private key pair and enable what hosts and ports you want to allow access using the TUNNEL_TOKEN. A configurable passphrase (in this case SECRETPASS) makes sure only the clients allow can connect.

TUNNEL_TOKEN=123 ./crisscross_server
$ crisscross tunnel_announce ^defaultcluster "*./keys/my_tunnel.yaml#Name"
True
$ crisscross tunnel_allow \
    "123" \
    "^defaultcluster" \
    "*./keys/my_tunnel.yaml#Name" \
    "SECRETPASS" \
    "www.httpbin.org" \
    80
True

Take the Name value from ./keys/my_tunnel.yaml and distribute it to the client. On the client instance, map your local port (in this example: 7777) to the destination and port on any node advertising the key pair name on the cluster.

$ crisscross tunnel_open \
    "^defaultcluster" \
    "<NAMEVALUE_FROM_SERVER>" \
    "SECRETPASS" \
    7777 \
    "www.httpbin.org" \
    80
True

Now your client will automatically find the server and you can access localhost:7777 on the client to reach www.httpbin.org:80 from the server instance.

SQL Engine

From Python or Redis you can access the SQL engine to run complex SQL queries on immutable trees. Currently its rather limited (no ALTER TABLE staments and no INDEX support). Those things are supported by the engine (GlueSQL) however are not currently connected to the storage layer and need to be hooked up.

For more usage see the Python client example

Files

Files are like any other tree, except they have integer keys and binary values. The keys represent the offset of the binary value in the original file. The python client and CLI provide a way to work with files:

$ crisscross upload Readme.md
2UPoQEnEf91mgvazZPBruCwNwTHsytfRQUbjvSVmQY3bhCj

Once you have a hash, a file behaves like a normal tree, you can query its keys to get specific chunks of the file, announce it, download it, and distribute it.

# Show file contents:
$ crisscross cat 2UPoQEnEf91mgvazZPBruCwNwTHsytfRQUbjvSVmQY3bhCj
# Download file:
$ crisscross download 2UPoQEnEf91mgvazZPBruCwNwTHsytfRQUbjvSVmQY3bhCj Readmecopy.md
# Announce file
$ crisscross announce ^defaultcluster 2UPoQEnEf91mgvazZPBruCwNwTHsytfRQUbjvSVmQY3bhCj
# Download remote file
$ crisscross download ^defaultcluster 2UPoQEnEf91mgvazZPBruCwNwTHsytfRQUbjvSVmQY3bhCj Readmecopy.md
# Copy a remote file to your local CrissCross instance with multiple connections
$ crisscross remote_persist --num=10 ^defaultcluster 2UPoQEnEf91mgvazZPBruCwNwTHsytfRQUbjvSVmQY3bhCj Readmecopy.md

Directories

Directories work in the same way. Directories are trees with string keys and embedded trees as values. The python client and CLI provide methods for manipulating and accessing directories

$ crisscross upload_dir ./examples
2UPqTuCGzngW5hR9BtuFaMdCJu2PJD1ygqfvbicFq3eenaq
# Add a file to an existing directory
$ crisscross upload_dir ./more-examples --tree=2UPqTuCGzngW5hR9BtuFaMdCJu2PJD1ygqfvbicFq3eenaq
2UPmgchaP1Z2Yr2YUQtG1eMQqbNBt1qtEtK93RutWdvQDny
$ crisscross download_dir 2UPqTuCGzngW5hR9BtuFaMdCJu2PJD1ygqfvbicFq3eenaq examples-copy
# List a directory's contents:
$ crisscross ls 2UPqTuCGzngW5hR9BtuFaMdCJu2PJD1ygqfvbicFq3eenaq
examples/streams.py
examples/tcp_tunnel.py

Speed

CrissCross was built with performance in mind. For large values, the primary speed consideration (besides disk speed) is hashing. CrissCross uses Blake2, however switching to a non-cryptographic hash (like xxH3) increases the performance of inserting 10mb chunks by about 2-5x.

In the future there may be an option for a non-cryptographic CrissCross with embedded storage for maximum performance.
